Measurement of the steering angle of the passenger bridge undercarriage

[Translate to chinese:] Drehgeber WDGA58B-Profinet im Fahrwerk der Fluggastbrücke

To help passengers exit the plane without complications its essential to position the passenger boarding bridge correctly on the runway. The PROFINET absolute rotary encoder WDGA 58B is cabable of detecting the exact position of the boarding bridge.
The encoder is available with different absolute interfaces.

Important features:
Encoder WDGA 58B PROFINET

EnDra^®: maintenance-free and environmentally friendly
PROFINET-IO, Single-turn/Multi-turn
Compact design with bus cover
Single-turn/Multi-turn (max. 16 bit/43 bit)
Forward-looking technology
2 colour-duo LED´s as indicator for operating condition and bus status and 2 L/A LED´s
High shaft load up to 220 N radial, 120
Unit profile: switchable, Class 3, 4

Encoder WDGA 58B PROFINET

Capture of fork motions of a forklift truck

[Translate to chinese:] Seilzugsystem im Gabelstapler

The SZG140 draw-wire-system is used to accurately measure the fork height of a forklift. and can be integrated into the mast to save space. It‘s also possible to detect sideways fork movements for automatic presetting to different pallet sizes. Our draw-wire-systems are available with rope lengths up to 40 m and incremental or absolute encoders.

Important features:

Measuring lengths up to 5.0 m
Compact housing
High resolution
Incremental and absolute versions
Quick mounting
High precision mechanics with high linearity

Draw wire system SZG140

Lifting platform

Lifting platforms are used in a wide range of industrial and domestic applications. In order to be able to move the platform to the desired height, it must be possible to determine an exact position. This can be achieved using the SZG165 wire rope hoist system. Reliable and accurate length measurement allows an exact position to be determined. The wire rope hoist systems are available in lengths up to 40 m.

Important features draw-wire system SZG60:

Ball bearing mounted swivel
Stainless steel measuring cable
Plain bearing guide
Quick mounting option
High resolution
Incremental and absolute versions
High precision mechanics with high linearity

Draw-wire system SZG60

Important features draw-wire system SZG165:

Ball bearing mounted swivel
Stainless steel measuring cable
Plain bearing guide
Quick mounting option
Measuring lengths up to 40.0 m
High resolution
Incremental and absolute versions
High precision mechanics with high linearity

Draw-wire system SZG165
